This is the most powerful Ranger from Polaris. It has 904 cc diesel engine. Carries 6 adults in total comfort . It features an isolation-mounted, fuel-efficient 24 HP YANMAR® diesel engine.
New RANGER CREW DIESEL has superior suspension travel, ground clearance and towing, add in class leading fuel range and the RANGER CREW DIESEL is the Hardest Working. Smoothest Riding. And is the only 6 passenger diesel out there.
The 2012 Polaris RANGER Crew Diesel UTV has a fuel-efficient, diesel engine which will help its owner to save money and ensure that this ATV will run more efficiently and even reach 90% of its max torque when it reaches full RPM plus it’s diesel engine offers more than 40% fuel range compared to other gas powered ATV’s.
The greatest thing is that true AWD keeps you moving, automatically engaging all four wheels when you need more forward traction and reverting back to 2WD when you don’t. When in 2WD, the VersaTrac Turf Mode switch unlocks the rear differential for easier, tighter turns that won’t tear up your grass.
Many people buy ATV for fun. Ranger is excellent choice. But, it is, also, a very capable working machine. The strength to tow 2,000 lbs. means you can tackle the toughest jobs, towing trailers and wheeled equipment with confidence. Features a standard 2” hitch receiver. 1000 lb capacity rear dump box has gas-assist dumping operation and features exclusive Lock & Ride cargo system that accommodates many hard-working accessories that can go on and off in seconds.
It is likely the most comfortable ATV on the market. The only four-corner adjustable suspension system. Dual A-Arm with exclusive top mounting-point adjustability. Adjust to softer setting for light-duty work or stiffer for heavy-duty work. The longer wheelbase of the RANGER Crew, combined with advanced long-travel suspension, create a smooth ride even when fully loaded. A full 11.5” of ground clearance adds to the comfort by clearing obstacles and moving smoothly through ruts and over rough terrain. Cab ergonomics deliver outstanding driver and passenger comfort, including tilt steering with the highest range of motion (10″), extra legroom, and easy cab slide-through design for six adults to get in and out quickly.
Comparison to other models:
Specifications
ENGINES
Engine Type 3-Cylinder Diesel
Displacement 904cc – 24hp
Fuel System Indirect Injection
Cooling Liquid
DRIVETRAIN
Transmission/Final Drive Automatic PVT H/L/N/R; Shaft
Drive System On-Demand True AWD/2WD/ VersaTrac Turf Mode
Engine Braking System/ Active Descent Control Not Equipped
SUSPENSION
Front Suspension Dual A-Arm 9.6″ (24.4 cm) Travel
Rear Suspension Dual A-Arm, IRS 9″ (22.9 cm) Travel
BRAKES
Front/Rear Brakes 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake Hand-Actuated
TIRES/WHEELS
Front Tires / Model 26 x 9-12; PXT
Rear Tires / Model 26 x 11-12; PXT
Wheels Stamped Steel
DIMENSIONS
Wheelbase 108″ (274.3 cm)
Dry Weight 1,660 lb (755 kg)
Overall Vehicle Size (LxWxH) 145 x 60 x 76″ (368 x 152 x 193 cm)
Ground Clearance 11.5″ (29 cm)
CAPACITIES
Fuel Capacity 9 gal (34.1 L)
Bed Box Dimensions (LxWxH) 36.5 x 54 x 11.5″ (93 x 137 x 29 cm)
Box Capacity N.A./1,000 lb (453.6 kg)
Payload Capacity 1,750 lb (793.8 kg)
Hitch Towing Rating 2,000 lb (907.2 kg)
Hitch/Type Standard/2″ Receiver
FEATURES
Cargo System Lock & Ride
Lighting 55W low/ 60W high, LED Tail
Electronic Power Steering Not Equipped
Instrumentation Digital Gauge, Speedometer, Odometer, Tachometer, Tripmeter, Hour Meter, Clock, Gear Indicator, Fuel Gauge, Hi-Temp/Low-Batt Lights, DC Outlets (3)8
